Pioneer XY-101

Opis

Hardware
Enclosure Type: Two-way passive, reflex-loaded
Rigging and Hardware:
• 8 × M8 threaded mountig points (4 top/4 bottom),
• 3 × M8 threaded mounting points on rear,
• 4 × M8 threaded mounting points on side (2 left/2 right),
• 4 × M6 threaded points on rear (for wall mount bracket),
• 1 × flush handle on rear,
• 1 × 35 mm polemount socket
Grille: Hex punched steel
Enclosure: 15 mm (0.6-inch) birch plywood
Finish: Impact-resistant, Black semi-matt textured

System data
Frequency response: 70 Hz to 20 kHz
Sensitivity (1W/1m): 94 dB
Nominal Impedance: 8 Ω

Loudspeaker data
Power Handling: 400 W RMS, 800 W Program
Power Handling AES: 120 dB cont., 126 dB peak
Power Handling (RMS/Program): 90 °H × 60 °V, rotatable
Transformer taps:
• 10 inch (250 mm) neodymium LF cone driver,
• 1 inch (25 mm) exit neodymium HF compression driver
Maximum SPL: Asymmetric internal passive crossover
Dispersion: 2 × Neutrik SpeakON™ NL4

Dimensions / Weight
Dimensions ( W x H x D): 292 × 508 × 280 mm (11.5 × 20 × 11 inch)
Weight: 14 kg (30.9 lbs)

Other
Suggested Power Amplifier:
• Recommended : K2DSP
• Minimum : M30DHDSP
Accessories: polemount socket cover (-W model only)
