Pioneer DJM-S5

Opis

Main Features
MIDI Control: Assignable (click here to see the details)
Compatible DJ Software: Unlocks Serato DJ Pro
DVS Control: Unlocks Serato DVS
Software System Requirements: Visit serato.com for its specifications.
What's in the Box: DJM-S5
USB cable
Quick Start Guide
Precautions for Use
Warranty (for some regions)

Specifications
Width: 245 mm
Height: 107.9 mm
Depth: 363.5 mm
Weight: 3.4 kg
Power Consumption: 5V/500mA
S/N Ratio USB: 108 dB (USB)
                       94 dB (LINE)
                       82 dB (PHONO)
                       75 dB (MIC)
                       94 dB (AUX)
Distortion: 0.003 % (USB)
                0.007 % (LINE)

Master
Level Meter Size: 7 segment

Channels
EQ/ISO: 3 band
EQ/ISO Range: –∞ dB to +6 dB

Performance Control
Channels: 2
Sound Color FX: Filter

Crossfader
Crossfader Type: MAGVEL FADER PRO

Mic
Mic Connection: XLR / 1/4-inch Combo Jack

Sound card
Connection: USB (Type-C)
Sample Rate: 24 bit
Frequency: 48 kHz

Terminals
Inputs: 2 PHONO/LINE (RCA)
           1 MIC (XLR & 1/4 inch Combo Jack)
           1 AUX (RCA)
Outputs: 1 MASTER (XLR)
             1 BOOTH/MASTER (RCA)
             2 PHONES (1/4-inch stereo jack, 3.5-mm stereo mini-jack)
USB: 2 sets USB Type-C port (PC/Mac connection & power supply ×1, Only power supply ×1)
