Opis
This Integrated amplifier works hard to maintain excellent stereo separation in order to achieve a wide and deep musical sound stage, all while minimising the interference. The SA10 Integrated amplifier features both a pre amplifier and a power amplifier for source switching, volume control and superior amplification.
A singer’s sharp intake of breath before hitting the chorus, a guitarist’s fingers sliding against the strings – it’s those seemingly minor details that can bring music to life. Fish out one of your all-time favourite albums and play it through a Bluetooth speaker, and guess what? Its sounds like a Bluetooth speaker. Play it through the SA10, and it’s as close to hearing the artist’s performance as you’re likely to get. There’s always joy in digging out an old recording you haven’t heard in years. With the HDA range, it’ll feel like hearing it forthe first time.
- Extremely efficient class A/B amplification
- 50W of power per channel
- 5 analogue inputs including phono
- 3 digital inputs
- 32-bit DAC,Sabre ESS9016K2M
- Full I/P control
- Total harmonic distortion + noise = 0.003%
Both Channels, 8Ω, 20Hz—20kHz | 50W |
---|---|
Single Channel, 4Ω, at 1kHz | 90W |
Harmonic Distortion, 80% Power, 8Ω at 1kHz | 0.003% |
Input Sensitivity At 1kHz | 5mV |
Input Impedance | 47kΩ + 100pF |
Frequency Response (ref. RIAA curve) | 20Hz – 20kHz ± 1dB |
Signal/Noise Ratio (A-wtd) 50W, ref. 5mV Input | 80dB |
Overload Margin, Ref. 5mV at 1kHz | 21dB |
Nominal Sensitivity | 1V |
Input Impedance | 10kΩ |
Maximum Input | 6Vrms |
Frequency Response | 20Hz – 20kHz ± 0.2dB |
Signal/Noise Ratio (A-wtd) 50W, ref. 1V Input | 106dB |
DAC | ESS9016K2M |
Frequency Response | 20Hz - 20kHz ± 0.05dB |
Total Harmonics Distortion + Noise | 0.0007% |
Signal/Noise Ratio (A-wtd) | 115dB |
Supported Sample Rates (Optical) | 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz |
Supported Sample Rates (Coaxial) | 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz |
Bit Depth | 16-bit – 24-bit |
Nominal Output Level | 630mV |
Output Impedance | 230Ω |
Maximum Output Level Into 600Ω | 5Vrms |
Output Impedance | 1Ω |
Load Range | 16Ω – 2kΩ |
Mains Voltage | 110–120V or 220–240V, 50–60Hz |
Maximum Power Consumption | 350W |
Dimensions W x H x D (including feet, control knob and speaker terminals) | 433 x 87 x 310mm |
Weight (Net) | 8.4kg |
Weight (Gross) | 10.7kg |
Supplied Accessories | Mains leads Remote control 2 x AAA batteries |
